Industrial Robots

• • Parallels

    •

      Hornet

      565

      Designed for Primary and Secondary Food Packaging

      Datasheet



      The Hornet 565 is a parallel robot for high-speed picking and packaging applications. The powerful controls are fully embedded into the base of the robot, saving valuable floor space and reducing installation costs and complexity. It features a hygienic design that minimizes contamination risks, including a standard IP65 rated work area and corrosion resistant materials for easy wash down.

      The Hornet includes a complete robot packaging solution that includes integrated high-speed conveyor tracking, powerful vision guidance, and easy-to-use application software created specifically for the packaging market. The robot can be programmed directly from a PLC, minimizing training and deployment time by using familiar ladder logic programming languages.

      • • Hornet 565 requires no external control electronics, with all amplifiers and controls fully embedded into the robot.
      • • Extended vertical reach allows for a 0.36 m3 (12.7 ft3) workspace, enabling a wider variety of packages to be used.
      • • 0.32 s cycle time enables higher product throughput and reduces cost per pick.
      • • Industry-leading conveyor tracking capabilities allow for < 5mm repeatability at all coveyor speeds (pending).


      Quatro

      650 / 800

      The Omron Adept Quattro robot is the only parallel robot in the world with patented features and USDA-accepted for meat and poultry processing.

      Datasheet



      The Quattro™ Parallel robot excels at high-speed applications in packaging, manufacturing, assembly, and material handling. It is the only parallel robot (or "delta robot") in the world with our patented four-arm rotational platform, delivering maximum speed, maximum acceleration and exceptional performance across the entire work envelope. Ultra-compact controls and embedded amplifiers improve footprint efficiency while simplifying installation.

      The high speed, precision and overhead-mount features of the Quattro robot make it the perfect choice for flexible and fast packaging, material handling, kitting, and assembly.

      • • Patented four-arm design.
      • • Robust components and design.
      • • High-resolution, absolute encoders.
      • • High-efficiency, low-inertia drives and lightweight arms.
      • • 8 kHz servo update rate yields high accuracy, superior slow-speed following, and easy calibration.
      • • Integrated temperature sensors monitor heat in servo motors to prevent damage.
      • • Diagnostic display on robot enables faster troubleshooting.
      • • Quattro S650HS model is USDA accepted for primary food handling.


      Sysmac Delta

      The fastest picking system integrated in the Sysmac platform.

      Datasheet



      The Delta solution can achieve up to 200 cycles per minute and can be synchronised with multiple conveyors to perform on-the-fly Pick & Place operations. There are 3 types of Delta robot arms available as Washdown, Delta and Mini Delta robot. The NJ controller offers a response time of 2 ms when controlling 8 Delta robots or 1 ms when controlling 4 robots.

      • • Control of up to 8 robots by one controller.
      • • Degrees of freedom: 3 + 1 (rotational axis optional).
      • • Up to 200 cycle per minute.
      • • Model range from 450 to 1600 mm working range.
      • • Payload range: 1 to 8 kg.
      • • IP class range: IP65, IP67, IP69K.

  • Scara

    •

      Cobra

      350 / 450 / 500 / 650

      Omron's Adept Cobra robot deliver performance unmatched in the industry.

      Datasheet



      High-performance SCARA robot system for mechanical assembly, material handling, packaging, machine tending, screw driving, and other applications that require fast and precise automation. Omron Adept Cobra Series robots deliver performance unmatched in the industry with the included SmartController™ motion controller.

      • • ACE software deploys your applications through a user-friendly interface.
      • • High-resolution, absolute encoders give you high accuracy, superior slow-speed following, and easy calibration.
      • • High-efficiency, low-inertia Harmonic Drives and a lightweight arm deliver maximum acceleration.
      • • 8 kHz servo update rate improves path following and control.
      • • Integrated 10/100 Base-T Ethernet TCP/IP to control the robot through a PC, PLC, or controller.
      • • Available options for cleanrooms and ESD to prevent static electricity during operation.


      eCobra

      600 / 800

      eCobra SCARA Robot Series offers a compact system footprint, saving valuable floor space while minimizing installation costs and complexity.

      Datasheet



      Omron's Adept eCobra 600/800 SCARA robot series features 600 or 800-mm reach and is available in three performance tiers, each designed to address different application complexity and throughput requirements. eCobra offers a compact footprint, saving valuable floor space while minimizing installation costs and complexity. This unique family ensures that users receive the highest quality, most durable robots at every performance level.

      • • All amplifiers and controls are fully embedded into the robot to maximize valuable floor space and reduce installation costs (cables, control cabinets, labor, etc.)
      • • Three performance levels (Lite, Standard, and Pro) based on a common hardware platform. Maximizes value by only paying for the performance required for the application, without sacrificing hardware quality.
      • • Upgrade performance with a software license download. Easily upgrade your robot to increase production throughput with a simple software upgrade.
      • • Advanced features such as direct PLC programming are included in Standard and Pro performance tiers- minimize training and deployment time using familiar ladder logic programming languages of existing PLC.
      • • Adept ACE™ provides an effective way to deploy applications, without lengthy, overly-complicated programming.
      • • Includes a powerful 3D emulator that allows complete system configuration and testing in a virtual environment.

  • Articulated

    •

      Viper

      650 / 850

      The speed and precision of Adept Viper six-axis robots make them ideal for operations requiring fast and precise automation.

      Datasheet



      The Adept Viper™ six-axis robot is a high-performance articulated robot ideal for assembly, material handling, packaging, machine tending, and many other operations requiring speed and accuracy in a 650mm or 850mm reach.

      • • Rapid deployment using familiar ladder logic programming languages of existing PLC (IEC 61131-3).
      • • Diagnostics display enables faster trouble shooting.
      • • Ethernet TCP/IP capability to control the robot through a PC, PLC, or robot controller.
      • • High-resolution, absolute encoders to provide high accuracy, superior slow-speed following, and easy calibration.
      • • High-efficiency, low-inertia Harmonic Drives and a lightweight arm to deliver maximum acceleration.
      • • Maximum payload 5 kg.
